Diodes

Edal diodes are miniature and medium current devices that offer reliable operation even under extreme humidity and other severe environmental conditions.


Flexible axial leads and compact construction facilitate circuit board applications and point-to-point wiring.


All diodes utilize simultaneously diffused, passivated junction techniques to assure stable and uniform electrical characteristics. Standard and fast recovery Bulk Avalanche types in voltage ratings from 50 to 1500 volts and currents from 200 mA to 6 amps are offered.


Edal's diodes have high surge currents and I2t ratings making them ideal for Pulsing circuits.



General Purpose 1 AMP to 6 AMP

lo
Product Series 1.0 AMP
BA5 1.0 AMP
1N4000 2.0 AMPS
B8 3.0 AMPS
M4 3.0 AMPS
BA491 3.0 AMPS
1N5000 3.0 AMPS
M5 5.0 AMPS
B823 5.0 AMPS
M7 6.0 AMPS

Fast Recovery Diodes

Product Series lo Trr.nSec.
BR5 1.0 AMP 400 to 500
BR8 2.0 AMPS 400 to 500
MR4 3.0 AMPS 400 to 500
MR5 5.0 AMPS 400 to 500
MR7 6.0 AMPS 400 to 500

Super Fast Recovery Diodes

Product Series lo Trr.nSec.
BS5 1.0 AMP 150 to 250
BS8 2.0 AMPS 150 to 250
MS4 3.0 AMPS 150 to 250
MS5 5.0 AMPS 200 to 300
MS7 6.0 AMPS 200 to 300

Extremely Fast Recovery Diodes

Product Series lo Trr.nSec.
BT5 1.0 AMP 50 to 100
HER1 1.0 AMP 50 to 75
BT8 2.0 AMPS 50 to 100
MT4 3.0 AMPS 100 to 150
HER5 5.0 AMPS 50 to 75
MT5 5.0 AMPS 150 to 200
MT7 6.0 AMPS 150 to 200
