Miniature High
Voltage Diodes

Available in a variety of packages ranging in current from 25 mA to 2 amps and voltage ratings from 2000 to 20,000 volts. Simultaneous diffused passivated junction techniques are utilized to assure stable and uniform electrical characteristics. Diodes are available in standard, fast recovery, Bulk Avalanche, and a variety of recovery times.


Standard Recovery Diodes

lo lo lo
Product Series 3KV Diode 5KV Diode 10KV Diode
B427 100 mA
B587 100 mA
B757 100 mA
B1064-2 220 mA
B588 300 mA
BA223 300 mA
B780 600 mA
B933 800 mA
B656 950 mA
B1776 1.15 AMPS
B697 1.60 AMPS
B932 2.0 AMPS

Fast Recovery Diodes

lo lo lo
Product Series 3KV Diode 5KV Diode 10KV Diode
B427 50 mA 250 nS
B587 50 mA 250 nS
B757 50 mA 250 nS
B588 150 mA 200 nS
BAR223 150 mA 200 nS
BR1064-2 250 nS
BR656 500 mA 300 nS

Extremely Fast Recovery Diodes

lo lo lo
Product Series 3KV Diode 5KV Diode 10KV Diode
BT757 50 mA 100 nS
BT588 150 mA 100 nS
B780 300 mA 100 nS
B1506 300 mA 100 nS
BT933 650 mA 100 nS
BT1776 1.0 mA 100 nS
BT697 1.5 AMPS 100 nS

Super Fast Recovery Diodes

lo lo lo
Product Series 3KV Diode 5KV Diode 10KV Diode
BS757 50 mA 150 nS
BS588 150 mA 150 nS
BS656 430 mA 200 nS
BS780 450 mA 150 nS
BS933 650 mA 150 nS
B1481 800 mA 150 nS
BS1776 1.0 AMPS 150 nS
BS697 1.5 AMPS 150 nS

Ultra Fast Recovery Diodes

lo lo lo
Product Series 3KV Diode 5KV Diode 10KV Diode
BU757 50 mA 60 nS
